| Voltage Protection Rating (UL 1449 3rd Edition, 3,000A) |
500V |
| Single Pulse Energy Dissipation |
2700 Joules |
| Peak Impulse Current |
135,000 Amps |
| LAN |
Wires Protected: 8-Wires
Compatibility: 10/100/1000 BASE-T
Clamping Level: 60 ± 5V |
| Coax |
Shielded: Yes
Insertion Loss: < 0.5 dB
HD 1080 i/p Ready: Yes
Frequency Range: 0 MHz – 2.2 GHz
Connections: Female “F”, Gold Plated
Clamping Level: 75V
Bidirectional: Yes |
| Family |
Pro Series |
| Line Voltage |
120 (Volts) |
| Number of Outlets |
9 |
| Number of Isolated Banks |
4 |
| Outlet Descriptions |
1 (always on, linearly filtered outlet, front panel)
6 (individually switchable, linearly filtered outlets)
2 (individually switchable, high current outlets) |
| Rack Mountable |
Yes |
| Control |
Full outlet control using BlueBOLT or Telnet commands. Limited outlet control through front panel buttons or rear panel DC trigger. |
| Voltage Regulation |
No |
| Compliance |
cCSAus |
| Low Voltage Trigger |
12V In |
| AC Protection Technology |
Protect or Disconnect
Automatic Voltage Monitoring
L-N, L-G, N-G Protection Modes
Thermal Fusing |
| Under-Voltage Shutoff |
100 VAC ± 2 VAC |
| Over-Voltage Shutoff |
134 VAC ± 2 VAC |
| Maximum Current Rating |
20 (Amps) |
| Initial Clamping Level |
200V Peak |
